Lifetime 90192 - Parts Identifier (Part 1); Pole and Extension Components; Frame Guards and Brackets

8
Parts shown at 10% of Actual Size
ALH (x1)
Top Pole
!,& (x1)
Middle Pole
ALE (x1)
Bottom Pole
PARTS IDENTIFIER
!** (x1)
,EFT"ACKBOARD"RACKET
!*+ (x1)
Right Backboard Bracket
38
”
43 ”
3/8
43 ”
3/8
27 5/8”
AKC (x2)
Short Extension Arm
ALI (x2)
Pole Brace
7ARNING3TICKER
30 1/16”
AKB (x2)
,ONG%XTENSION!RM
AKQ (x1)
Inner Channel
ALB (x1)
Outer Tube
21 3/4 ”
!*$ (x1)
1/2” x 21 3/4” Axle
!*8 (x2)
Corner Frame Guard
!*1 (x1)
Center Frame Guard
21 1/8”
