PARTS LIST
ID Item Description Qty
!,( Top Pole 1
!,& Middle Pole 1
!,% Bottom Pole 1
AJK Right Backboard Bracket 1
AJJ ,EFT"ACKBOARD"RACKET 1
AJI Backboard 1
AJX Corner Frame Guard 2
AJQ Center Frame Guard 1
!,8 Rim 1
AKC Short Extension Arm 2
AKB ,ONG%XTENSION!RM 2
AKQ Inner Channel 1
!," Outer Tube 1
AKI Handle Grips 2
CNG Handle Brace 1
AJM Base 1
!,) Pole Brace 2
AMU Wheel 2
AJD 1/2” x 21 3/4” Axle 1
AKP Height Sticker 1
AMT Warning Sticker (Applied to Middle Pole) 1
CPI Front Adjust Parts Kit
AKZ Net 1
CNJ Outer Tube Bushing 1
!,, Pole Bracket 1
AJN Base Cap 1
!,- Pole Cap 1
!,$ Plastic Guard 1
AJY Counterbalance Spring 2
AMN Trigger 2
AJS Channel Stop 1
CNF ,OCK4AB 1
ID Item Description Qty
Pole Assembly Hardware (1068524)
ADS 1/4” x 3/4” Screw 2
ABZ Xv3ELF4APPING3CREW 2
AAF 3/8” Washer 2
ABB 3/8” Centerlock Nut 2
ABE 3/8” x 4” Hex Bolt 2
ABR 1/2” x 3.41” Spacer 2
CIH Domed Countersink Washer 2
HARDWARE LIST
