Lifetime 90192 - Hardware Identifier (Part 3); Backboard to Pole Hardware Details; Handle Assembly Hardware Details

13
AAD (x4)
1/2” x 7 1/16” Hex Bolt
!!8 (x4)
1/2” Center
lock Nut
ABL (x4)
.69” x .59” Black Spacer
ABN (x4)
1/2” x 1/8” Spacer
HARDWARE IDENTIFIER
"!#+"/!2$4/0/,%!33%-",9(!2$7!2%
Hardware shown at Actual Size
7 1/16”
(Not actual length)
AAN (x1)
5/16” Cap Nut
7”
(Not actual length)
ABO (x2)
1/2” x 1” Poly Spacer
ABB (x1)
3/8” Centerlock
Nut
AAD (x1)
1/2” x 7 1/16” Hex Bolt
7 1/16”
(Not actual length)
AAZ (x1)
3/8” x 7” Hex Bolt
(!.$,%!33%-",9(!2$7!2%
Hardware shown at Actual Size
CNH (x2)
vXv5.#!3CREW
AZP (x2)
1/4” Nylock Nut
ADR (x4)
#7 x 3/8” Phillips Screw
