HANDLE ASSEMBLY
PARTS REQUIRED
SEC
5
Parts shown at 10% of Actual Size
AKQ (x1)
Inner Channel
ALB (x1)
Outer Tube
Parts shown at 25% of Actual Size
AKI (x2)
Handle Grip
!*3 (x1)
Channel Stop
!*9 (x2)
Counterbalance Spring
AMN (x2)
Trigger
TOOLS REQUIRED
Phillips Screwdriver
vvv
7RENCH(x 2 Each)
v7RENCH(x1)
AKP (x1)
Height Sticker
#.' (x1)
Handle Brace
#.& (x1)
,OCK4AB
#.* (x1)
Outer Tube
Bushing
Rubber Mallet
