Lifetime 90192 - Page 38

38
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
Attach the ,OCK4AB#.& to the Triggers (AMN) with the hardware shown,
and slide the Trigger Spring (AQH) onto the Triggers in the locations
shown.
SEC
5.1
AMN
AQH
ADR
ADR (x4)
Position the Trigger Assembly onto the (ANDLE"RACE#.' as shown.
Place the (ANDLE'RIPS!+) on the Handle Brace over the Triggers.
SEC
5.2
#.&
#.'
AKI
AQH (x2)
AQH
AMN
ADR
ADR
ADR
AKI
