Manual F5021B - System overview
opening times)
8 Duplex-function Via the second CAN-Bus 2 lifts can be conectetd to a two- groupe. The
lifts than parting calls respective to the actual situation; so it can be
achieved that the times of waiting can be reduced to a minimum. In
addition there can be activated a function, that, if there are no more open
calls, the one of the lifts which is nearer the main stop position, gets
driven there an keep it prepared there.
9 Group function With a optional group controler board, lift groups with up to 8 lifts can
be realized. The group control collects the hall calls and allocate these
respectivlly to the condition of the several lifts in order to reach short
time of waiting.
10 Rush hour handling – fill up
building
Via internal time frame inputs, the capacity can be adapted to the
building. (type office buildings)
11 Rush hour handling – clear building Via internal time frame inputs, the capacity can be adapted to the
building. (type office buildings)
12 Distribution of waiting lifts If there are no more open calls, the lifts of the groupe get distributed
after 1 min. in the buildding, means one drives to main stop position, the
others disperse themself, in order to achieve shorte waiting times.
13 Interface to building control service
engineering
RS485 interface for connection to a PC of the building control service
engineering.
14 Remote control The lift can be integrated into a region comprehensive remote control
system.
15 Lift arrival gong During the drive in, the gong on the cabin roof or under the cabin floor,
about the arrival of the lift.
16 direction indicator HOP Inside the exterior panels it is possible to instal an optical and akustical
continued travel display.
17 Floor gong For every stop an lift arrival gong can be arranged.
18 Card reader in the cabin With a transponder card, either a specific call can be activated or
defined calls can be approved.
19 Card reader at the floor Approval of exterior calls
20 Selective door triggering Frontside and backside of the lift can be controlled seperatly.
21 Scramble After one minute the door is closing slowling despite of the safty light
barrier.
22 VIP Service A key switch in exterior panels cancels all hall calls and fetches the
empty cabin. Now multiple interior calls can be done. After these calls
are done, the lift change back to standard handling.
23 PIN entry via Push buttons For certain floor approvals the Push buttons can be used for entering a
PIN.
24 Local controlled floor approval For several and duplex lifts a changed floor approval via key switch can
be activated.
25 Via group controlled floor approval Floor approvals can be temporary changed via the group add-on.
26 Temporary block of sereral floors Temporary, the user can block floors
27 Automatic evakuation In case of black out with following auxiliary power supply, the cabine
will be driven to the next stop.
28 Auxiliary power supply evakuation For lift groups an evakuation will be done separate one after another
29 Earthquake function Lift get stopped during the drive and will be driven to the evaktuaion
stop.
30 Voice message Serial and parallel access for voice message
Page 6
