Page #8 background imageLoading...
Page #8 background image
Manual F5021B - System overview
At the floors, the Exterior call buttons and key buttons will be conected with the AM04 modules
(Display + CAN-module) for special features. Newer modules also allow the conection of a speaker
to make possible the, in EN81-70 required, „tones“.
Extra module SM09
Via this module client specific special features can be complemented without changing the central
module. For example the conection to lift-maintenance-systems of the client or additional alerts,
etc.
Function overview
Standardfunktionen
1 Collectioncontrolling Collecting hall calls with respect on the given direction
2 Inspection Drive Manual drive up and down. Within the area of doors, the door open
button can be used for opening the door.
3 Self liberation with slow drive In case of missing the door area within the normal mode, the lift is
driving slowly with closed safets circuit into flush position and open the
door.
4 Test dive For Testcases, the lift can do a indicated number of accidentally test
drives.
5 Real time clock Errors are registred with date and time. Time-dependent funktions can
be activated.
6 Time to keep doors open Dependent of the kind of call(interior, exterior, service, special call), the
time to deep doors open can be indicated.
7 Door opening by lokal call Is the lift allready in the floor from which the call comes, the door
opens. With the Door open button, the door can be keept in open
position
8 Early door closing With the Close door button, the door can be closed, earlier than the keep
door open time frame.
9 Forced opening of doors Inside the door area, with the Door open botten, the door opening can be
forced for closed doors or doors which are actually close.
10 Controlling of door closing.
(return motion automatic)
In case the bar is not closed within 15 sec. after arrival at the door-close-
endswitch, the door open again for a new try.
11 Controlling of door opening In case that 15 seconds after the door opened and the door-opend-
endswitch is not activated, the door is closing until further command.
12 Call cancel By doubble-pushing a call button, the call is canceled.
13 Terminal stops At paramount stage the up command gets canceled, at the lowermost
stage the down command gets canceled.
14 Direct drive Direct drive without rat run. This function is activated at standard when
incremental detection and analog trigger of the inverter.
The driving cycle is preset by the controller. There are no special
demands on the inverter.
15 Cabinet full If full load, the cabinet do not stop anymore for hall calls.
16 Cabinet light cut off After 5 minutes without any activity, the cabinet light will be switched
off.
17 Park drive After an indicated time without any activity, the lift drives to the main
purchase postion.
18 LCD controller Graphical display with comprehensive status informations and menu
navigation.
19 Analoge speed control The rotation speed of the frequency inverter is triggered by the analog
output
Page 4
