Manual F5021B - System overview
20 Digitale speed control Alternatively the speed can be controlled via contactors
21 Error memory The last 20 Errors get saved and displayed with information of time,
floor and error code.
22 Learn trip for schaft information The controller is learning with encoders and floor flags the bulk of the
schaft and stopping distance. After that, the lift can merge into standard
mode.
23 Floor approval Free adjustments of floors, which can be departed.
24 Adjustment of the floor display The icons, which should appear in the respective floors, can be free
adjusted to a large extent.
25 Liftboy control The lift gets drived via interior control manually. Hall calls will be
served.
26 Priority inside Hall calls are deactivated only interior calls are effective. The door must
be closed with the door-close-button. The Push-button have to be
compressed until the close-door-end-switch is activated.
27 LED-dot matrix-display,
LCD graphic-display
At every stop there ist a dot matrix display with floor update, direction
and status. The user can see that there is something going on.
28 Display with roll function Respectively to the drive direction, the display is „rolling“.
29 Automatic schaft data correction Continously the schaft datas gets corrected
30 Remote off The lift can be shut down, but before all still open cabinet commands
need to be completed.
31 Door only opens inside the door
areas
Outside the door areas, the cabinet doors can not be opened.
32 Safty light barrier/ light gate The safty light barrier/ light gate gets evaluated by the controller. In case
of activation, the controller avoids closing the door.
33 Overload In case of overload, the door stay open and an alert sounds (buzzer)
34 Abuse recognition If the cabinet is empty (empty load) the number of cabinet calls is
bordered.
35 Stop in case of wrong agitator
direction
In case the controller recognize a wrong agitator direction the handler
gets stopped.
36 Drive inspection (skidding) If the cabinet is not moving despite active handler, the handler gets
stopped after 40 seconds (drive inspection). New drives only possible
after Reset.
37 Inspection of traction In case of cabinet is moven despite deadlock, alarm get raised.
38 Inspections end switch The inspections end switch avoid, that the lift drives to the emergency
limit switch during inspections, return motion drives or learn trip.
39 Contactor monitoring The controller check at every drive the correct functionallity of the main
contactors and brake contactor .
40 Speed monitoring If over speed is detected an emergency stop will be effected
41 CPU monitoring The processor is monitored by watchdog, if needed restarted.
Optionale functions
1 preopening doors Using safty circuit
2 relevelling with open doors Using safty circuit. At hydraulic lifts standard function
3 Fire controll In case of fire signal the lift drive to the fire floor and stay there with
open door.
4 Fireman control All commands get canceled and the lift drives to the fire floor stage.
Now the firemen can use the lift. The door is not open atuomatically, but
have to be opened with the door-open-button. Unhand the button makes
the doors closing immediatelly.
European (EN81) und Russian (PUBEL) variant.
5 Additional COP It is easy to install a second car operation panel
6 COP for 2
nd
door Selective door control
7 Disabled COP Particular COP (e.g. desk COP) for disabled people (longer door
Page 5
