Contents catalogue
Thank you for choosing our product! This fixture is the same as our other models, The design and production are all
through comprehensive quality control to ensure the excellent performance , and maximum to approach the customers'
satisfaction and demand.
1. Please read all the contents of this manual and keep it for your reference.
2. During the using of this manual for maintenance, please pay attention to the following points:
A. Prepare for maintenance, includes the maintenance tools.
B. Make good records of maintenance and repair.
C. Take the photos as record before disassembly the part to sure that all parts can be easily remounted.
D. All the parts and screws should be placed separately to avoid mistake.
3. Do not cut the belt, even if the light is equipped with spare belt.
4. No repairing and maintenance is allowed with Power ON, keep safe;
5. Make sure the failure reason is found before dismantle the fixture.
6. The maintenance requires professional skill.
7. The part that it's not listed in Service Manual, please refer to ‘User Manual’.
8. The copyright of this service manual is owned by Fly Dragon lighting equipment Co. Ltd, brand LIGHTSKY.
Attention：
Based on the fixture’s continuous upgrade , the data or part contained in this manual
are probably to be changed in the future. while Our company reserves the right to change
the relevant information in following product improvement without the further notice.
The publisher of this manual is not responsible for the accuracy of the information in this
manual and will not be responsible for the consequences associated with the information.
1.The installation and routine maintenance.................................................................................................2
2. The maintenance method and attentions..................................................................................................3
3. The treatment of exceptional falt...............................................................................................................4
4. The exploded view....................................................................................................................................8
5. 0 lamp dismounting and mounting................................................................................................22 IP300
6. IP series X Motor replacement...............................................................................................................24
7. IP series Y replacement................................................................................................................28 Motor
8. IP series X/Y Motor drive PCB ........................................................................................34 replacement.
9. .....................................................................................36IP series CMY and color wheel replacement..
1
