A, Motor ROAD must keep balance with Motor axis
B, gear can not be fixed in advance , but must keep in its position to make sure the X sensor
is in its centor position. After the motor put in fixture position, then , fix the gear screws.
find outthe
good position
of gear
Motor Road
Pan sensor
Gear Position
motor Road
After the motor is installed,
then, fix the gear position
7.Please remember to intall the belt , and reconnector the cables before fix the screws
PAN MOTOR.Then , install those parts from step 7,6,5,4,3,2,1.
.
27
6.Replace the Pan Motor, here are two position need to pay attention
