Lighthouse ApexRemote Operating Manual
1-2 248083447-1 Rev 1
WARNING: The use of controls, adjustments or procedures
other than those specified within this manual may result in
personal injury and/or damage to this instrument. Attempts
by untrained personnel to disassemble, alter, modify or
adjust the electronics or optics may result in personal injury
and damage to the instrument and will void its warranty.
There are no user-serviceable components inside the
particle counter. Only factory authorized service personnel
should repair or service this instrument and its optical
system.
Review Lighthouse specifications before installing a DC
power supply, gateway or PoE switch that will be
designated as a power source for the ApexRemote.
Attempting to use under-rated power source equipment can
expose the instrument, adjacent equipment and the user to
dangerous shock and fire hazards. Failure to meet the
specifications as provided by Lighthouse Worldwide
Solutions will void the instrument Warranty and CE
certification and may cause serious personal injury.
WARNING:
The
ApexRemote PoE can
use a standard Ethernet
Cat6 cable and separate
24V AC-DC power
supply. It connects to the
round connector shown
on the right in Figure 1-1.
The symbol shows the
voltage and polarity of
supplied power. Handle
with care and keep away
from water or conductive
liquids.
Figure 1-1 SmartPort, Ethernet and 24VDC Power Connectors
Electrostatic
Safety
Information
Electrostatic discharge (ESD) can damage or destroy electronic
components. Therefore, any service or maintenance work should be
done at a static-safe work station. A static-safe work station requires an
ESD consultant to evaluate the work environment and propose the
equipment and apparel needed for just such a work station to be
successful.
