DIP Switch Definitions
Table 4-1 displays the general DIP Switch settings. OFF (UP) = 0, ON
(DOWN) = 1
Note: Use a tool with a
very small pointed tip in
order to change the DIP
Switch positions.
Table 4-1 DIP Switch settings
Communication Modes
There are three communication modes for the ApexRemote family.
The ApexRemote Serial has options for MODBUS ASCII and
MODBUS RTU. Table 4-2 displays those modes. The ApexRemote
PoE communicates using MODBUS TCP.
Position
#
Description Setting
1 Binary Bit 0 Addressing, OFF=0, ON=1
2 Binary Bit 1 Addressing, OFF=0, ON=1
3 Binary Bit 2 Addressing, OFF=0, ON=1
4 Binary Bit 3 Addressing, OFF=0, ON=1
5 Binary Bit 4 Addressing, OFF=0, ON=1
6 COM Mode See Table 4-2
7 Serial Protocol UP = use DIP Switch Addressing
DOWN = Serial Settings from
Instrument Setup Tool
8 Reserved
Table 4-2 DIP Switch Settings for ApexRemote Serial COM Mode
COMMUNICATIONS MODE
DIP
SW 6
MODBUS ASCII (UP) OFF
MODBUS RTU (DN) ON
