Lighthouse ApexRemote Operating Manual
2-4 248083447-1 Rev 1
Size Range 0.3 - 5.0 μm
Channel Thresholds Standard 2-channel: 0.3μ, 0.5μm
Standard 4-channel: 0.3μ, 0.5μ, 1.0μ, 5.0ȝm
Optional 6-channel: 0.3μ, 0.5μ, 0.7μ, 1.0μ, 3.0μ,
5.0ȝm
Flow Rate 0.1 CFM (2.83 LPM)
Counting Efficiency 50% (per ISO 21501-4)
Data Storage Rotating Buffer, 3000 records
Light Source LASER diode
Zero Count Level <1 count/5 minutes (per ISO 21501-4)
Calibration NIST Traceable
Communication Modes MODBUS ASCII; MODBUS RTU; MODBUS
TCP
ISO Probe Maximum
Tubing Length
From ApexRemote Inlet to ISO Kinetic Probe =
10 ft (3.0 M)
Supporting Software LMS Pharma/Pro v7.3.1 or higher, LMS Express
7.5 or higher; LWS Instrument Setup Tool 1.3.5 or
higher
Power Input Requirements 24VDC ±5% @ 250mA via LMS 485 Gateway
for ApexRemote Serial, PoEswitch for
ApexRemote PoE (IEEE 802.3af compliant) or
optional AC/DC supply for ApexRemote PoE
Power Supply
Specifications
Optional Listed LPS Power Supply, Output 20-
26VDC 400mA (10W) min, ApexRemote PoE,
only
Enclosure Stainless Steel, VHP compatible
Dimensions 6.38” (w) x 4.59” (h) x 2.94” (d) [16.21 x 11.66 x
7.5 cm]
Weight 1.4 lbs (0.63 kg)
Operating Temp/RH 50° F to 104° F (10° C to 40° C) / 20% to 95%
non-condensing
Storage Temp/RH 14° F to 122° F (-10° C to 50° C) / Up to 98% non-
condensing
Table 2-2 ApexR03 Specifications
