ApexRemote MODBUS Register Map v1.50
248083447-1 Rev 1 A-5
40060 signed integer Last Sample Timestamp [high] (# of seconds since midnight, 1/
1/1970.).
40061 signed integer Last Sample Timestamp [low].
40062 signed integer Last Setting Change Timestamp [high] (# of seconds since
midnight, 1/1/1970.). Value indicates.
40063 signed integer Last Setting Change Timestamp [low].
40064 signed integer Run-time particle channel alarm high flags (bit 0 = channel 1,
…).
40065 signed integer Run-time particle channel alarm low flags (bit 0 = channel 1,
…).
40066 signed integer Run-time analog channel alarm high flags (bit 0 = channel 1,
…).
40067 signed integer Run-time analog channel alarm low flags (bit 0 = channel 1,
…).
40068 unsigned integer Software controlled RGB LED red channel. Uses values from
0-100 for duty cycle percentage every even second from UNIX
time.
40069 unsigned integer Software controlled RGB LED green channel. Uses values
from 0-100 for duty cycle percentage every even second from
UNIX time.
40070 unsigned integer Software controlled RGB LED blue channel. Uses values from
0-100 for duty cycle percentage every even second from UNIX
time.
40071 unsigned integer Software controlled RGB LED red channel. Uses values from
0-100 for duty cycle percentage every odd second from UNIX
time.
40072 unsigned integer Software controlled RGB LED green channel. Uses values
from 0-100 for duty cycle percentage every odd second from
UNIX time.
40073 unsigned integer Software controlled RGB LED blue channel. Uses values from
0-100 for duty cycle percentage every odd second from UNIX
time.
Table A-3 Sensor Settings Registers
Register Data Type Description
