Version 1.0 Page 30 / 43
About EDID router
EDID router contains a 116 block non volatile memory bank. EDID List is structured
as follows:
1..50 .....................................................................Factory Preset EDID list
51..100 ........................................................User programmable memories
101..108 ( DVI_OUT_1...8) ............................Attached monitor’s EDID list
109..116 ( DVI_IN_1...8).......................emulated EDID at input conenctors
Info The first 50 EDID (1…50 inclusive) are factory preprogrammed and cannot be
modified. These are the most commonly used resolutions.
Info The attached monitor’s EDID is stored automatically, until a new monitor is
attached to that particular output. In case of powering the unit off, the last attached
monitor’s EDID remains in non volatile memory.
Table4. -Factory Preset EDID list
MEMORY Resolution MEMORY Resolution
01 640x480@60 Hz
