Charging of battery
When the mains cable is plugged in and a control button is activated
the symbol to the left is shown on the display until power down 2
minutes later. The purpose of the symbol is to tell the user that it is
not possible to use the lift when it is plugged in to the mains.
Short circuit
SHORT CIRCUIT
If there is a short circuit the control box will show the short circuit
symbol with a recommendation to check the connections.
The symbol will be shown until the short circuit has been repaired.
Service
The control box will show the service symbol when it is time for
service. The standard setting is after 12 months/8000 cycles. After
each power down, the first time that the service symbol is shown the
control box will provide an audio sound (100 milli seconds) so that the
user gets a reminder about checking the display.
The ‘SERVICE’ text will blink 3 times, then a static service symbol will be shown (10 seconds in total). Even
though it is time for service the system will still be functional and work as normal.
Overload Channel 1 only
When overload occurs (according to the pre- defined current cut-off
limit) the overload symbol will be shown on the display. The ‘MAX’
text will blink 3 times and the overload symbol will be shown for 10
seconds in total.
Service information read-out
Basic service information can be read out on the display. To get the service information on the display
please press the lifting arm up button (only ½ second press). The information will be shown for ½ minute
or until other buttons are activated.
12034
1257000
7
90/360
Total cycles done on channel 1
Total work done on channel 1
Total number of overloads (channel 1)
Days since last service/Days between services
If “No days” are chosen for service interval then the display will show Days since last service /-.
