CASE BACK CONTROLS - STANDARD AND ADVANCED MODELS
1. POWER CORD LOCATION
2. GAS CONNECTION, GMAW AND FCAW
3. GAS CONNECTION, GTAW
4. OPTIONAL - 115 VOLT, 10 AMPS 60 Hz
RECEPTACLE FOR GENERAL USE -
K2829-1
FIGURE B.3
POWER WAVE 300C OPERATION
®
B-6
5. CIRCUIT BREAKER
6. ETHERNET CONNECTOR
3
2
4
5
6
1
