57 With both flat head screws removed, re-
move counterbalance weights (Item 2).
58 Remove inner and outer retaining ring
(Item 5 and Item 3) from both sides.
59 Place assembly on 2 1/2” dia. steel pipe
included in tool kit.
60 Drive crank eccentric (Item 6) out of ball
bearing (Item 7).
61 Drive ball bearing (Item 7) out of crank
rod (Item 4).
62 Remove O-Ring seal (Item 33) from
outlet nut (Item 32).
18
