10.11 Info
• Device information for service.
11. Content of report printout
Leakage test
**** Lindab LT600 ****
Version 1.0
Leakage test
**** Lindab LT600 ****
Version 1.0
Notes on the printout
Make and model of device
Firmware version
Test report ID# 148
DIN EN 12237 compliant leakage test
report for duct system
DIN EN 1507 and DIN EN 12599
Test report ID# 149
DIN EN 12237 compliant leakage test
report for duct system
DIN EN 1507 and DIN EN 12599
Consecutive test number
Test object information
Surface area: 121.2 m²
Airtightness class: B
Rate factor
RF: 9 l/s 1/m²
Adapter type: none
Pressure setting: 100 Pa
Test pressure: 99.3 Pa
Leakage flow rate: 11.20 l/s
Test duration: 117 sec
Limit for A: 64.86 l/s
Limit for B: 21.62 l/s
Limit for C: 7.20 l/s
Limit for D: 2.40 l/s
Result:
Test object
Test passed
Date: _20.01.2012
Time: 14:11.
Signature:
Test object information
Surface area: 121.2 m²
Airtightness class: U
Rate factor
RF: 8 l/s 1/m²
Adapter type: none
Pressure setting: --- Pa
Test pressure: 206.6 Pa
Leakage flow rate: 15.65 l/s
Test duration: 0 sec
Limit for A: 104.44 l/s
Limit for B: 34.81 l/s
Limit for C: 11.60 l/s
Limit for D: 3.86 l/s
Result:
Test object
Not passed
Date: _20.01.2012
Time: 14.11.
Signature:
Specified surface area
Selected airtightness class
Leakage flow rate used for analysis
Specified adapter type
Preset pressure (not in laboratory
mode)
Mean pressure actually achieved
Actual leakage flow rate in l/s
Test duration (not in laboratory mode)
Permitted leakage flow rates for
the pressure actually achieved – for
information only
Whether the tested system complies
with the airtightness class
• The printout on the left is an automatic test with airtightness class B, which was stopped after 117 s. (The auto-
matic test duration is 300 s)
• The printout on the right is a test in laboratory mode with a variable (non-standard) airtightness class of 8 l/s m²,
printed after an arbitrary test duration.
