Emergency exit for trucks with rear windscreen Operation
Emergency exit for trucks with rear wind-
screen
NOTE
If the truck is fitted with a front and rear windscreen, it
may not be possible to dismount at the side if the truck
breaks down in a narrow aisle. In case of acute danger,
the driver can leave the truck through the rear window. To
do so, the driver must destroy the window with an
emergency hammer.
- Pull the cotter pin (1) out of the mounting (2) located at the
right side below the armrest on the cover of the additional
electric equipment.
- Take the hammer (3) out of the mounting and cautiously
break the window pane.
WARNING
Risk of injury!
- Remove any pane remnants.
- Carefully dismount from the truck through the rear window.
1
2
3
E335-2/165
e336-2/082
1
Emergency exit for trucks with polycarbo-
nate rear windscreen*
NOTE
If the truck is fitted with a front and rear windscreen, it
may not be possible to dismount at the side if the truck
breaks down in a narrow aisle. In case of acute danger,
the driver can leave the truck through the rear window. To
do so, the driver must destroy the window with an
emergency hammer.
- In case of acute danger completely loosen the four star
knobs (1) counter clockwise.
- To open, push the rear windscreen with light pressure
outside.
- Carefully dismount from the truck through the rear window.
NOTE
In trucks with a polycarbonate rear window the emergency
hammer is not fitted.
* Option
