Linear AE-500 User Manual

5
220793 F IMAGE 5
Wiring Diagram
16 VAC
20 VA
TRANSFORMER
EARTH
GROUND
STAKE
DOOR EXIT
REQUEST
BUTTON
12 VOLT
BATTERY
REMOTE
KEYPAD
PWR
GND
DAT1
DAT0
DVAL
PCLK
POWER
TERMINALS
AC2
AC1
DC -
DC +
EARTH GROUND
DVAL
DAT0
DAT1
GND
PWR
PCLK
KEYPAD
TERMINALS
COM
N.O.
N.C.
COM
N.O.
N.C.
RELAY
TERMINALS
RELAY "A"
RELAY "B"
GND
RTE-B
GND
RTE-A
DS-A
INPUT
TERMINALS
TELEPHONE
TERMINALS
TIP
EARTH GROUND
RING
ELECTRIC
DOOR
STRIKE
RELAY RATING:
3 AMPS @ 30 VOLTS
AC/DC MAXIMUM
TELEPHONE
JACK
DOOR
STRIKE
POWER SUPPLY
DOOR
SENSE
CONTACT
CASE
GROUND
STUD
NOTE: OPTIONAL
BACKUP BATTERY
WILL REQUIRE AN
EXTERNAL CHARGER
GATE
OPERATOR
OPEN
AE-500
THIS WIRING EXAMPLE SHOWS PRIMARY ACCESS WITH A DOOR STRIKE ON RELAY CHANNEL "A"
AND SECONDARY ACCESS WITH A GATE OPERATOR ON RELAY CHANNEL "B"
REMOTE KEYPAD
FOR GATE ENTRY
GATE
EXIT LOOP
SENSOR
TO DEDICATED
TELEPHONE LINE
CONNECT TELEPHONE LINE TO
TERMINALS OR TELEPHONE JACK
EARTH
GROUND
12-24 VOLTS
AC/DC
