Linksys EtherFast Instant Broadband BEFW11S4 User Manual

3. Click Upgrade Firmware. A new page will appear.
4. Enter your Router’s administration password into the Password box.
5. Click the Browse button and find the firmware upgrade file that you
downloaded from the Linksys website. Double-click the upgrade file.
This will place the file into the “File Path:” box.
6. When the correct file is in the “File Path:” box, click the Upgrade button
and follow the instructions there. This will complete your firmware
upgrade.
EtherFast
®
Wireless Access Point + Cable/DSL Router with 4-Port Switch
30
EtherFast
®
Wireless Access Point + Cable/DSL Router with 4-Port Switch
Help
Here you will find links to all of the Utility’s internal support documentation,
a link to Linksys’s website, the application that upgrades the Router’s
firmware.
To upgrade the Router’s firmware:
1. Download the latest firmware version from the Linksys website
(www.linksys.com).
2. Go to the Help screen (above).
29
In order to upgrade the Router’s firmware, you must use
Internet Explorer 5.0 or higher, or Netscape Navigator 4.7 or
higher. Upgrading the firmware may cause the Router to be
reset to the factory defaults. Make a record of all settings
before attempting the upgrade.

Linksys EtherFast Instant Broadband BEFW11S4 Specifications

General

Wireless Standard	802.11b
Frequency Band	2.4 GHz
Security	WEP
Data Transfer Rate	11 Mbps
Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.11b
Wireless Data Rates	11, 5.5, 2, 1 Mbps
Modulation	CCK, DQPSK, DBPSK
Power	12V DC, 1A
Operating Humidity	10% to 85% Non-condensing
Storage Humidity	5% to 90% Non-condensing
LED Indicators	Power, WLAN
Operating Temperature	32 to 104°F (0 to 40°C)
Storage Temperature	-4 to 158°F (-20 to 70°C)
LAN Ports	4 x 10/100Base-TX (RJ-45)
WAN Port	1 x 10/100Base-TX (RJ-45)
