Linksys PAP2 Installation Guide
Page 2
2 Adapter Description
The sections below briefly describe the PAP2 device.
2.1 PAP2 Overview
The PAP2 is a 2-port FXS phone adapter, which allows you to connect two (2) analog
phones.
PAP2 2-Port FXS Phone Adapter
2.2 Connectors and Pinouts
The image below displays the Ethernet (RJ-45) and analog (RJ-11) line pin-outs.
Ethernet (RJ-45) and Analog (RJ-11) Line Pin-Outs
2.3 Accessing the PAP2
1. Connect an analog phone to the RJ-45 connector on the PAP2.
2. Using the telephone keypad, press the star key (*) four (4) times:
****.
You will be prompted to enter a code.
3. Enter the appropriate code, followed by the pound (#) key. Refer to the PAP2
Menu Options table on the following page for codes.
