Connecting the extender to an existing access point
If your access point or router supports it, you can use Wi-Fi Protected Setup to connect the range
extender to the access point or router. Log in to the browser-based utility and click on WPS in the
left navigation bar. Choose from the setup methods below to connect the extender.
NOTE
If you have an access point or a router that does not support Wi-Fi Protected Setup,
note the wireless settings, and then manually configure the extender. Connecting with the Wi-Fi
Protected Setup Button Use this method if your router or access point has a Wi-Fi Protected Setup
button
1. Press the Wi-Ff Protected Setup button on the extender. If you have a dual-band
router you will do this again to extend the second network . The 2.4 GHz band will
be extended first
2. Click the Wi-R Protected Setup button on the routef`s WiFi Protected Setup
