Lippert Components Ground Control 2.0 - Page 7

Rev: 05.23.2017
Contact us: Lippert Components Inc. - www.lci1.com/support - Phone: (574) 537-8900 - Email: customerservice@lci1.com
GROUND CONTROL
®
- 4 POINT ASSEMBLY
LEVELING AND STABILIZATION
Footpad Detail
Snapper PinSnapper PinSnapper Pin
Landing
Gear
Harness
Power and
Ground
Harness
Rear
Jack
Landing Gear
Controller
LCD
Touch
Pad
Rear Sensor
Rear Sensor
Harness
Set Screw
Manual
Override
Nut
LCD Touch
Pad Harness
Foot Pad
Bolt-On
Pull Pin
Motor
Gearbox
Mounting
Bracket
