Appendix D—Outline Dimensions for Air Operated Valve and Strainer
5566-XA Air Operated Valve (AOV) Assembly for the PT/PTH30 Pumps
4680-X Strainer Assembly for the PT/PTH30 Pumps
Inches (centimeters)
4.92
(12.50)
3.99
(10.12)
4.75
(12.07)
2.81
(7.14)
2.31
(5.87)
2.81
(7.14)
2.38
(6.03)
2.38
(6.03)
5.00
(12.70)
5.00
(12.70)
5.00
(12.70)
4.41
(11.20)
Inches (centimeters)
