Appendix E—Part Details for the PT/PTH30 Strainer
4680-X
Strainer Assembly
1
2
3
4
3
6
7
1
5
3
No. Part Number Description Qty.
1 7001-050NC125A Hex head bolt 8
2 4682 Strainer body cap 1
3 5596 Flange gasket 3
4 4681 Strainer basket 1
5 4680 Strainer body 1
6 5573 3 in. NPT flange 1
7 7001-050NC175A Hex head bolt 4
33
