IMA 578BLA Maxmig 210 Page 17
# Indicates a change this printing.
* Items not illustrated.
ITEM DESCRIPTION PART NO. QTY. 123456789
1 Motor Control PCB AS4212-4SP 1 X X
2 Choke Assembly AM3484 1 X X
3D* Insulating Tube T7028-226 2 X X
3E* Insulating Washer AT2882 4 X X
4 Liftbale Seal S12934 1 X X
5 Bulkhead Assembly AL2491 1 X X
7 Fan Motor AS4233-1 1 X X
9 Fan Blade AM3285 1 X X
Fan Blade (code 1641 and above) AM3285-1 1 - X
10 Roof and Door Assembly AG1343U 1 X -
Roof and Door Assembly AG1343-1 1 - X
11 Fan Shroud and Bracket Assembly AM3450-1 1 X X
12 Rectifier AL2480-2 1 X X
13 Rear Panel AL2486 1 X X
14 Rubber Buffer AS4404-1 2 X -
Magnetic Catch AS4532 2 - X
15 Cord Grip Grommet AT3764-1 1 X X
16 Input Lead AS2373-2 1 X X
17 Gas Hose Assembly AS4150-1 1 X X
18 Base and Axle Assembly AM3279-2 1 X X
19 Wheel AS4071-1 2 X X
Axle Push Nut AT2876 2 X X
20 Gas Solenoid AM3399-1 1 X X
Brass Bard Straight Tail AT3730-3 2 X X
21 Earth Tag AT3166 1 X X
22 Terminal Block AT3070-2 1 X X
23 Auxiliary Transformer PT0052 1 X X
24 Spool Post AM3387SP 1 X X
Spacer Washer AS4482 1 X X
25 Contactor AM3423-1 1 X X
26
5
/
32
” X
1
/
2
” Blind Rivet AT3425-2 1 X X
27 Transformer Assembly AL2535-1 1 X X
28 4” Swivel Castor AS4070 2 X X
29 Front Panel Assembly AL2537-2 1 X -
Front Panel Assembly AL2537-4 1 - X
Top Panel Assembly AL2537-4 1 - X
30 Rotary Sw Reworked- 8 Pos AS4559 1 X X
32 Bushing T12380-2 1 X X
33 Bushing T14614-2 1 X X
35 Lead - Sec.Tap to(-) Stud NSS 1 X X
36 Thermostat T14542-1 1 X X
41* Lead Harness AG1375 1 X X
51* Side Panel AL2487U 1 X -
Side Panel AL2487-1 1 - X
52* Side and Reel Shelf AL2488U 1 X X
53* Wiring Diagram AL2597 1 X X
54* Warning Decal AS4244 1 X X
55* Warning Decal AT3378 1 X X
56* Ground Cable Assembly AS4092-4 1 X X
58* Regulator/Flowmeter 94001310 1 X X
59* Chain AT3873 1 X X
60* Warning Tag AS3234 1 X X
62* Literature AL1369-119 1 X X
63* Pallet AM3288 1 X X
Use only the parts marked “X” in the column under the
heading number called for in the model index page.
AP-82-C1
Operative: 4.7.03
Supersedes: 28.10.98
Recommended Spare Parts are highlighted in bold
Nut, bolt and washer sizes are given so they may be procured locally.
