IMA 578BLA Maxmig 210 Page 27
MAXIDRIVE 2R
PARTS LIST AP-93
AP-93
Operative: 4.7.03
Supersedes: 28.10.98
Do not use this Parts List for a machine if its code number is not listed. Contact the Service Department
for any code numbers not listed.
Numbers in the table below indicate which column to use in each parts list for each individual code
number.
Sub Assembly
Item No. 1 2 3 4 5
Sub Assembly
Page Name
Machine Part List No. AP-93-C AP-93-D AP-93-W IMA580BLA
Description
Code No.
1547 05-1022 1 1 AM3574 IMA592LA
General Assembly
Drive Plate Assembly
Specification No.
Wiring Diagram
Instruction Manual
To Next Page
