IMA 578BLA Maxmig 210 Page 19
# Indicates a change this printing.
* Items not illustrated.
ITEM DESCRIPTION PART NO. QTY. 123456789
1 Front Panel (code 1483) AL2532-2 1 X -
Front Panel (codes 1539 and above) AL2532-3 1 - X
2 Microswitch Pushbutton AT3561-1 2 X X
3 Toggle Switch SPST T13562 1 X X
4 Knob 0.76” Spot Timer T10497 1 X X
5 Knob 1.3” Voltage T10491F 1 X X
6 Indicator - Over Temp. AT3384-1 1 X X
7 Pilot Light AS4460-1 1 X X
8 Moulded Output Stud AM2464-1 2 X X
11 Gun Adaptor AM3025-2 1 X X
12 Cord Grip Grommet AT3764-2 1 X X
13 Cable AS4462-1 1 X X
14 Wire Drive Mtg Brkt. AM3390-1 1 X -
Wire Drive Mtg Brkt AM3390-2 1 - X
17 Drive Roll 0.6 - 0.8mm Steel AS4449-9 1 X X
Drive Roll Adaptor AM3391-3H 1 X X
18 Drive Roll Cap Screw AM3391-1R 1 X X
19 Drive Plate AM3391-5 1 X X
20 Sleeving AM3058-412 1 X X
21 Sleeving AM3058-161 1 X X
22 Drive Motor AM3366-1 1 X X
23 Potentiometer 100k/SW 3A 125V AS4212-2 1 X X
24 Potentiometer 1k AS4212-1 1 X X
25 Toggle Switch DPDT AT3440 1 X X
26 Rotary Switch 8 Position 16 amp AM3388-1 1 X X
Use only the parts marked “X” in the column under the
heading number called for in the model index page.
AP-82-C1
Operative: 4.7.03
Supersedes: 28.10.98
Recommended Spare Parts are highlighted in bold
Nut, bolt and washer sizes are given so they may be procured locally.
