IMA 578BLA Maxmig 210 Page 23
# Indicates a change this printing.
* Items not illustrated.
ITEM DESCRIPTION PART NO. QTY. 123456789
2 Choke Assembly AM3484 1 x
3D Insulating Tube T7028-226 2 x
3E Insulating Washer AT2882 4 x
4 Liftbale Seal S12934 1 x
5 Bulkhead Assembly AL2491 1 x
7 Fan Motor AS4233-1 1 x
9 Fan Blade AM3285 1 x
Fan Blade (code 1642 and above) AM3285-1 1 x
10 Roof AK2489U1 1 x
11 Fan Shroud & Bracket Assembly AN3450-1 1 x
12 Rectifier AL2480-2 1 x
13 Rear Panel AL2486 1 x
15 Cord Grip Grommet AT3764-1 1 x
16 Input Lead AS2373-2 1 x
18 Base and Axle Assembly AM3279-2 1 x
19 Wheel AS701-1 2 x
Axle Push Nut AT2876 2 x
21 Earth Tag AT3166 1 x
22 Terminal Block AT3070-2 1 x
23 Auxiliary Transformer PT0052 1 x
24 Spool Post AN3387 1 x
Spacer Washer AS4482 1 x
25 Contactor AM3423-1 1 x
27 Transformer Assembly AL2535-1 1 x
29 Front Panel Assembly AL2655-1 1 x
30 Rotary Sw Reworked - 8 pos AS4559 1 x
35 Lead - Sec Tap to (-) Stud AM3040A437 1 x
36 Thermostat T14542-1 1 x
41 Amphenol Socket base Assembly AS4407-8 1 x
51* Side Panel AL2487-1 1 x
52* Side and Reel Shelf AL2488U 1 x
56* Ground Cable Assembly AS4092-5 1 x
58* Regulator / Flowmeter 94001310 1 x
59* Chain AT3873 1 x
65* Lead Assembly - Lt to Thermo /42B AS4453-5 1 x
66* Upper Side Panel AL2487-2 1 x
67* Maxidrive 2R Wirefeeder 05-1022 1 x
Use only the parts marked “X” in the column under the
heading number called for in the model index page.
AP-95-C1
Operative: 4.7.03
Supersedes: 28.10.98
Recommended Spare Parts are highlighted in bold
Nut, bolt and washer sizes are given so they may be procured locally.
