IMA 578BLA Maxmig 210 Page 29
# Indicates a change this printing.
* Items not illustrated.
ITEM DESCRIPTION PART NO. QTY. 123456789
1 Base Front and Rear AG1410 1 x
2 Vibro Isolator AS4404-3 4 1
3 Bulkhead AL2648 1 x
4 Motor control PCB AS4212-4SP 1 x
5 Gas Solenoid 42V AM3399-1
Brass Male Straight Tailpiece AT3730-3 1 x
Brass Male Elbow Tailpiece AT3070-9
6 Earth Tag AT3166 1 x
7 Red Microswitch AT3561-1 2 x
8 Toggle Switch Spot T13562 1 x
9* Lead Harness AL2652 1 x
10 Potentiometer insulation T12T92-1 2 x
11 Nameplate AM3572-1 1 x
Fastener Button (black) T14659-1 4 x
12 Wire Feed Pot AS4212-2 1 x
12a Rheostat Knob T10491 1 x
13 Spot Timer Pot AS4212-1 1 x
13a Rheostat Knob T10491D 1 x
14 Bulkhead Support AM3577 1 x
15 Spool Post AM3387SP 1 x
Spacer Washer AS4482 1 x
16 Gun Adaptor Reworked AS4456-1 1 x
17 Drive Plate Assembly AM3391-8 1 x
18 Insulating Washer AT2882 2 x
19 Plastic Washer/Tube AM3391-1S 2 x
20 Wire Drive Mounting Bracket AM3390-2 1 x
21 Drive Motor and Gearbox AM3185 1 x
22* Insulating Splice T12068-1 1 x
23* Cable Tie 10 x
24 Cable Assembly AL2656-1 1 x
25 Magnetic Catch AS4554 2 x
26 Door and Roof Assembly AG1411 1 x
27 Rubber Buffer AS4404-1 1 x
28 Handle M15446 1 x
29 Side Panel AL2650 1 x
30 Motor and Gear Box AM3185 1 x
Use only the parts marked “X” in the column under the
heading number called for in the model index page.
AP-93-C1
Operative: 4.7.03
Supersedes: 28.10.98
Recommended Spare Parts are highlighted in bold
Nut, bolt and washer sizes are given so they may be procured locally.
