IMA 578BLA Maxmig 210 Page 33
# Indicates a change this printing.
* Items not illustrated.
ITEM DESCRIPTION PART NO. QTY. 123456789
Complete Torch 102P953D30
10 Contact Tip ECu ø, M6 x 25mm 340P___1073
10 Contact Tip CuCrZr 340P___3073
10 Contact Tip for Alu 341P___1073
40 Gas Nozzle conical NW 12mm 345P012002
41 Gas Nozzle tapered NW 9.5mm 345P013002
42 Gas Nozzle cylindrical NW 16mm 345P011002
43 Gas Nozzle bottle form NW 13mm 345P014002
44 Gas Nozzle spot welding NW 16mm 345P015402
50 Torch Neck Maxmig 50, 50
o
bent 102P001002
54 Sleeve 102P002019
56 Nozzle Spring 102P002011
57 Nozzle support (l.h. thread) 102P002037
58 Head Insulator 102P002003
59 Insulating Hose (L=100mm) 101P002003
62 Hex Nut M10X1) 101P002005
65 Brass Body 600P002126
66 Torch Body PVC 600P002017
70 Handle Blue compl. 2-pol 380P220400
71 Switch Red, 2-poles 385P021016
72 Screw (PU=12 pcs) 100P008413
121 TBi-Flex cable 16mm
2
3m 360P161130
121 TBi-Flex cable 16mm
2
4m 360P161140
135 Cable lug 375P000023
136 Trigger wire connector, male 375P000004
160 Spring support small 600P102099
162 Adapter support 701P001045
163 Screw M4 x 6 100P008401
164 Adapter nut PVC 701P002081
170 ESG-connector, complete 701P001002
174 O-Ring 365P100040
175 Trigger wire connector, female 375P000003
176 Liner positioning nut M10 x 1 701P002005
180 Liner white 3m 324P133834
1.3 x 3.8mm for wire 0.6-0.9mm
180 Liner white 4m 324P133844
1.3 x 3.8mm for wire 0.6-0.9mm
180 Liner blue 3m 324P154534
1.5 x 4.5mm for wire 0.8-1.0mm
180 Liner blue 4m 324P154544
1.5 x 4.5mm for wire 0.8-1.0mm
186 Teflon liner blue 3m 326P154034
1.5 x 4.0mm for wire 0.8-1.0mm
186 Teflon liner blue 4m 326P154045
1.5 x 4.0mm for wire 0.8-1.0mm
190 Support tube for teflon liner, L=150mm 329P544150
193 Collet for teflon liner up to ø 4.0mm 331P020040
195 Collet for liner 2.5 x 4.5 330P025045
200 O-Ring for teflon liner 365P150035
Use only the parts marked “X” in the column under the
heading number called for in the model index page.
AP-103-E.1
Operative: June 2003
Supersedes: NEW
Recommended Spare Parts are highlighted in bold
Nut, bolt and washer sizes are given so they may be procured locally.
Insert wire dia. eg. 08 for 0.8mm
