LR-3200 Receiver Manual 11
BATTERY & BELT CLIP
Low Battery Indication
When the unit detects a low battery condition it will cause the status LED to ash slowly indicating that the
unit needs to be charged. When the light begins to ash the unit has approximately 3 hours of receiver use
before the unit will turn o.
Status LED: Begins to ash
when receiver has less than
an estimated 3 hours use left
on the charge
Belt Clip Installation/Removal
To remove belt clip, remove screw and pull belt clip from
unit. To install place belt clip in place and insert screw.
Accessing Battery Compartment
To access the battery compartment simply
remove the belt clip and battery door by
pulling down and out on the battery door
locking tab. Note: The product labeling
information can be found behind the
battery and includes the product model
number, description, serial number, contact
information and compliance statement.
