Listen Technologies LR-3200 - LR-4200 Quick Reference

LR-3200 Receiver Manual 5
LR-4200 QUICK REFERENCE
 PowerOn/O
Press and hold for 1 second to turn on. Press and hold for 3 seconds to turn o.
Up/Down Volume Control
Press momentarily to adjust the volume up/down or press and hold to ramp the volume.
Note: Press and hold both up and down buttons for 5 seconds to activate channel select,
use up and down to change the channel. Momentarily press the power button to save and exit.
Micro USB
USB charging, programming, rmware updates and inventory dispensing.
3.5 mm Output Jacks
Connect Listen Ear Phone/Neck Loop Lanyard for use with T coil hearing aids or with
Universal Ear Speaker or Headphone.
Belt Clip
To remove, remove screw and pull belt clip from unit. To install place belt clip in place
and insert screw.
Charging Contact
For use with Listen charging tray options.
LED
Indicates unit is on, low battery condition, and charging status.
Battery Protective Pull Tab
Remove clear plastic pull tab to activate internal battery connections.
Battery Door
Can be removed to access battery and product labeling information.
1
2
3
4
5
6
7
9
8
Up/down
Volume Control
2
Micro USB
3
5
6
9
8
3.5 mm Output Jacks
Belt Clip
Charging Contact
LED
Battery Protective Pull Tab
Battery Door
4
Power On/O
1
7
