Page 14 HIRO BUGGY Stroller for Special Needs Children Revision 2
ATTENTION! When adjusting the seat, pay particular attention to potential pinch points
created by the movable elements.
7.5 Backrest angle adjustment
The backrest (1) can be set in three positions by moving the seat (3) forward or backward. Fig. 15 shows the seat position and
backrest angle adjustment. Move the locks (2) toward and move the seat (3) to one of the three available positions. There is
possibility to set backrest both siting and semi reclining positions
Fig. 15
ATTENTION! When adjusting the backrest, pay particular attention to potential pinch
points created by the movable elements.
ATTENTION! It is recommended to adjust the backrest angle when the seat is unloaded.
After regulations make sure that pins are locked on both sides of seat
7.6 Preparing for adjusting supporting elements
For making adjustments on backrest easier in upholstery were specially made zipped flap on back of stroller cabin. Fig. 16.
