LIXiSE LXC3120 User Manual

LXC31X0/LXC93X0 Generator controller user manual
Dongguan Tuancheng Automation Equipment Co.,LTD.
LXC31X0/LXC39X0 User Manual Dongguan Tuancheng Automation Equipment Co.,LTD.
: T:+86 769-23162896 : F:+86 769-23166296  :www.lixise.com Page 13 of 28
23
Gen V Phase Sensing
1.0mm
2
Connected to V-phase of generator (2A fuse is
recommended)
24
Gen W Phase Sensing
1.0mm
2
Connected to W-phase of generator (2A fuse is
recommended)
25
Gen N2 Input
1.0mm
2
Connected to N-wire of generator.
26
Mains R Phase Voltage
Sensing
1.0mm
2
Connected to R-phase of mains (2A fuse is
recommended) (LXC3X10 without)
27
Mains S Phase Voltage
Sensing
1.0mm
2
Connected to S-phase of mains (2A fuse is
recommended) (LXC3X10 without)
28
Mains T Phase Voltage
Sensing
1.0mm
2
Connected to T-phase of mains (2A fuse is
recommended) (LXC3X10 without)
29
Mains N1 Sensing
1.0mm
2
Connected to N-wire of mains (LXC3X10 without)
30
RS232 public grounded
pin
0.5mm
2
Recommended to use shielded cable, single-grounded
shield(LXC31X0 series:no this function)
31
RS232 RX
0.5mm
2
32
RS232 TX
0.5mm
2
USB
USB Interface
Controller directly through the USB line connected to the
computer for parametric programming.
7. Parameters setting
Start the controller, then press to enter into the parameters setting menu, see fig below:
7.1. Password Management

The controller has 2 different password:
Technician Password
：
Default password: 0000; No. 72 passwords can be changed.
Operator password
：
Default password: 1111; No. 73 passwords can be changed.
 Password Privilege Description：
Technician Password：Has the authority to modify all parameters.
Operator password：You can view the parameters of the project, do not have permission to modify
parameters.

If there is need to set more parameters, please contact the factory.
 NOTES:
1
For LXC3X10, there are no items from 1 to 5 in Table 1; there are no digital outputs about
mains .
1 Ser Parameters
2 Information
3 Language
4 Mode Select
