LXC31X0/LXC93X0 Generator controller user manual
Dongguan Tuancheng Automation Equipment Co.,LTD.
LXC31X0/LXC39X0 User Manual Dongguan Tuancheng Automation Equipment Co.,LTD.
: T:+86 769-23162896 : F:+86 769-23166296 :www.lixise.com Page 22 of 28
Defined resistive range
is(0-6000)Ω
Is there a difference if standard curve of sensor with the use of sensors,can be change by itself in the
custom curve,when the sensor selection is "no", the curve of sensor doesn't work.
If the corresponding sensors, only alarm switch, is the sensor must be set to "no", otherwise likely
7.8. Conditions of crank disconnect
Magnetic pickup +Generator Frequency
Oil pressure+Generator Frequency
Oil pressure+Magnetic pickup
Oil pressure+Magnetic pickup +Generator Frequency
There are 4 conditions to make starter disconnected with engine,that is,speed sensor, generator
frequency ,Charge D + and engine oil pressure. They all can be used separately. We recommend
that engine oil pressure should be using with speed sensor and generator frequency together, in
order to make the starter motor is separated with engine immediately and can check crank
disconnect exactly.
Speed sensor is the magnetic equipment which be installed in starter for detecting flywheel teeth.
When set as speed sensor, must ensure that the number of flywheel teeth is as same as setting,
otherwise,“over speed stop”or“under speed stop”may be caused.
If genset without speed sensor, please don’t select corresponding items, otherwise, “start fail”or“loss
speed signal”maybe caused.
If genset without oil pressure sensor, please don’t select corresponding items.
If not select generator in crank disconnect setting, controller will not collect and display the relative
power quantity (can be used in water pump set);if not select speed sensor in crank disconnect setting,
the rotating speed displayed in controller is calculated by generator frequency and number of poles.
