LIXiSE LXC3120 User Manual

LXC31X0/LXC93X0 Generator controller user manual
Dongguan Tuancheng Automation Equipment Co.,LTD.
LXC31X0/LXC39X0 User Manual Dongguan Tuancheng Automation Equipment Co.,LTD.
: T:+86 769-23162896 : F:+86 769-23166296  :www.lixise.com Page 5 of 28
 Mains Monitor：With over voltage, under voltage, over frequency, under frequency, loss phase and
reverse phase function;
 Gens Monitor：With over voltage, under voltage, over frequency, under frequency, loss phase and
reverse phase function;

Acquisition parameters
：
Temp. (WT) °C/ °F both be displayed
Oil pressure (OP) kPa/Psi/Bar all be displayed
Engine Speed (RP) RPM (Unit)
Battery Voltage (VB) V (unit)
Charger Voltage (VD) V (unit)
Hours counter (HC): Max. 999999 hours
Start times: Max.999999 times

Protection: Automatic start/stop of the genset, ATS(Auto Transfer Switch) control with perfect fault
indication and protection function;
 Output Control：With ETS, idle control, pre-heat control, speed raise control and speed drop control,
All output ports are relay-out;
 Parameter Settings：All the parameters can be adjusted using front panel of the controller or use the
computer through USB to connect directly to controller settings, all is not lost when power down
parameter system;

Sensor Detection
：
More kinds of curves of temperature, oil pressure, fuel level can be used directly
and users can define the sensor curves by themselves;

Multiple Crank Disconnect Conditions
：
Gens frequency,speed,oil pressure,D+;

Widely Power supply range: DC(8~35)V, suitable to different start battery voltage environment;
 Mounting Assembly：Modular design, anti-flaming ABS plastic enclosure, plug gable connection
terminals and embedded installation way; compact structure with easy mounting.
3. Specification
Items
Contents
Working Voltage
DC8. 0V to 35. 0V, Continuous Power Supply.
Overall Consumption
<3W(Standby mode: ≤2W)
AC voltage Input:
3 Phase 4 Wire
2 Phase 3 Wire
Single phase 2 Wire
3 Phase 3 Wire
15V AC - 360 V AC (ph-N)
15V AC - 360 V AC (ph-N)
15V AC - 360 V AC (ph-N)
30V AC - 620 V AC (ph-ph)
Alternator Frequency
50 Hz /60Hz
Speed Sensor Voltage
1.0V to 24V (effective value)
Speed Sensor Frequency
10,000 Hz (max)
Start Relay Output
5A DC28V power supply
Programmable Relay Output 1
5A DC28V power supply
Programmable Relay Output 2
5A DC28V power supply
Programmable Relay Output 3
5A DC28V power supply
Programmable Relay Output 4
5A AC250V voltage-free output

LIXiSE LXC3120 Specifications

General

Brand	LIXiSE
Model	LXC3120
Category	Controller
Language	English
