LXC31X0/LXC93X0 Generator controller user manual
Dongguan Tuancheng Automation Equipment Co.,LTD.
LXC31X0/LXC39X0 User Manual Dongguan Tuancheng Automation Equipment Co.,LTD.
: T:+86 769-23162896 : F:+86 769-23166296  :www.lixise.com Page 4 of 28
1. Summary
LXC31X0 Series automation controller uses 32-bit ARM processor, the module is realized intelligent
generator control technology.There are used for genset automation and monitor control system of single
unit to achieve automatic start/stop, data measurement, alarm protection.It fit with LCD display, optional
languages interface (Chinese, English, Spanish and Russian), and it is reliable and easy to use.It’s
achieve a precision measuring,fixed value adjustment, time setting and set value adjusting and etc.All
parameters can be configured from front panel or through programmable USB interface via PC. It can
be widely use in all types of automatic genset control system with compact structure, advanced circuits,
simple connections and high reliability.
2. Performance and characteristics

LXC3XX0 indicates 2 series,totally 4 type modules
：
 LXC3X10 indicates LXC3110，LXC3910

LXC3X20 indicates LXC3120
，
LXC3920
 LXC39X0 indicates LXC3910，LXC3920

LXC31X0 indicates LXC3110
，
LXC3120
 LXC3X10：ASM (Automatic Start Module),it controls generator to start/stop by remote signal;
 LXC3120：AMF (Auto Mains Failure), updates based on LXC3110, moreover, has mains electric
quantity monitoring and mains/generator automatic transfer control function, especially for automatic
system composed by generator and mains.
 LXC39X0：Based on LXC31X0,add RS232 interface and can be remotely monitored by LXI680
integrated with related PC software.
Its main features are as follows:
 Display：132×64 LCD with emerald green backlight；

Language
：
Chinese, English, Spanish and Russian
；
 Operating：good feeling button pushing, long button life；

Suitable for
：
3-phase 4-wire, 3-phase 3-wire, single phase 2-wire, and 2-phase 3-wire systems with
voltage 120/240V and frequency 50/60Hz.
 Detection parameters:
Mains
Gens
Line Voltage
Uab，Ubc，Uca
Line Voltage
Uab，Ubc，Uca
Phase Voltage
Ua，Ub，Uc
Phase Voltage
Ua，Ub，Uc
Frequency
Hz
Frequency
Hz

Load
：
Current IA，IB，IC
Active Power (KW)
Reactive Power (KVar)
Apparent Power (KVA)
Power Factor (PF)
Accumulated Energy (kWh)
