LXC31X0/LXC93X0 Generator controller user manual
Dongguan Tuancheng Automation Equipment Co.,LTD.
LXC31X0/LXC39X0 User Manual Dongguan Tuancheng Automation Equipment Co.,LTD.
: T:+86 769-23162896 : F:+86 769-23166296  :www.lixise.com Page 20 of 28
24
Simulate Stop key
An external button can be connected and pressed as simulate panel.
25
Simulate Manual key
26
Simulate Manual Test key
27
Simulate Auto key
28
Simulate Start key
29
Lamp Test
All LED indicators are illuminating when input is active.
7.6. Programmable output 1-5
No.
Type
Description
0
Not Used
1
Fuel Relay
Action before the starter motor, open the fuel system in advance.
Usually controls the governor's power and fuel solenoid valve.
2
Crank Relay
When starting the motor action, often connected to the starter relay.
3
Air Flap
Action in over speed alarm stop and emergence stop. It also can
close the air inflow the engine.
4
Audible Alarm
Action in warning,shutdown,trips.Can be connected outside
alarm.When programmable input port is active of“alarm mute”, can
prohibit its output.
5
Louver Control
Action in genset starting and disconnect when genset stopped
completely.
6
Fuel Pump Control
It is controlled by fuel pump of level sensor’s limited threshold.
7
Heater Control
It is controlled by heating of temperature sensor’s setting bound.
8
Excite Generator
Output in start period. If there is no gens frequency during hi-speed
running, output 2 seconds again.
9
Pre-Lubricate
Actions in period of pre-heating to safety run.
10
Idle Control
Used for engine which has idles.Pull in before starting and pull out
after into hi-speed warming; Pull in during stopping idle mode and
pull out after shutdown completed.
11
Raise Speed
Action in hi-speed warming run.
12
Drop Speed
Action in period of stop idle mode to time of wait for stopping completely.
13
ETS Control
Used for engines with ETS electromagnet. Pull in when stop idle is
over and pull out when set“ETS delay”is over.
14
Close Generator
Generator load conditions are ripe for action, control power closing
switch with load. It is a continuous output.
15
Close Generator Pulse
The same role,but is not a continuous output, but only the output
pulses of a preset time.This time set in the timer configuration.
16
Open Generator
Generator stop action, control power generation closing switch uninstall.
17
Open Generator Pulse
The same role,but is not a continuous output, but only the output
pulses of a preset time.This time set in the timer configuration.
18
Open Breaker
Gens whether or mains is opened, will be output. It is a common
sub-gate output.
19
Close Mains
Control switch of mains is load.
20
Close Mains Pulse
21
Open Mains
22
Open Mains Pulse
23
Generator OK
Action when gens are normal.
24
Generator Available
Action in period of gens normal to hi-speed cooling.
25
Crank Success
Pull in when detects a successful start signal.
26
Mains OK
Action when mains are normal.
