Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 87
Layout Type Example
Grid
For systems composed of three or more
sensors. Sensors can be mounted in a 2-
dimensional grid using the settings in the
Layout Grid area below. Side-by-sideand
top-bottom configurations are supported,
as well as combinations of these and
reversed orientations.
