Dispensing5
5.1.2.2 Continuous Mode
This mode of operation is used for wettings of varying lengths or for the application of beads.
● With the pressure regulator 8 set the dispensing
pressure to 0.50 bar (approx. 7 psi). An error
message „ Press. 0.83 NOK “ with beeping is
possible. The value 0.83 [bar/psi] is only an
example for the indicated dispensing pressure
(see Chapter 7).
● Press button to store the dispensing
pressure setting as the comparison value for
automatic pressure monitoring.
The error message with beeping is eliminated.
● Press button . The lighting of the LED in
button indicates continuous mode. The
indication of the dispensing time in the digital
display is set to 0.00 s and blinks.
● Press the Footswitch 15 until the dispensed
quantity is roughly achieved.
When the dispensed quantity is achieved too slowly:
● Increase the dispensing pressure and store. Check the dispensed quantity again.
Repeat this sequence until the desired dispensed quantity is roughly achieved.
☞
– Switching back to time controlled mode without storage of the dispensing time by renewed
pressing of button . The LED in button extinguishes. In the digital display, the dispensing time
previously stored for the time controlled mode reappears.
– Switching back to time controlled mode with storage of the dispensing time by pressing
button . The LED in button extinguishes. The indicated dispensing time is stored and the
display stops blinking.
If the desired dispensed quantity is not achieved:
● With a larger (or smaller) dispensing needle, repeat the steps of Section 5.1.2.2.
