Where the function POWER is the same as described previously in this manual (power
indication on or off), the button ESC will bring you back to the system parameters menu.
With the
▼▲
keys you can select the power indication to be ON or OFF, and NEXT will
bring you to the next item of the SET DISPLAY menu. Beside the parameters RPM, HEART
RATE, TORQUE, TIMER and DISTANCE two more are parameters are added: TARGET
HEART RATE and ENERGY.
Selecting the target HR parameter will show you the target heart rate programmed in the heart
rate controlled protocol beside the actual heart rate. For instance:
Selecting the energy parameter will show you the total amount of mechanical energy
delivered by the test subject going into the ergometer in the form of mechanical motion,
during the exercise test.
Instead of 2 items you can show 4 items out of your selection at once, they will scroll in
groups of 2. When you select 4 parameters, there will be no scrolling but a fixation on the
display of these parameters. You can program the parameters (also up to 4 without scrolling)
at the basic control panel as well, but you have to switch the control over to the basic side first
as is described in the next paragraph.
The menu
SETTINGS
will give you the opportunity to select PROTOCOL as a default
startmenu besides the previously described menus ANALOG, MANUAL, TERMINAL and
SYSTEM PARAMETERS.
An extra option for the Programmable control unit in the menu SETTINGS is the
CONTRAST adjustment for the P-display. Adjusting contrast shows direct effect on the
display. Only after confirmation with SAVE the new contrast is kept!
B.3.6 Operation from basic control panel
With the basic control panel as described previously in this manual you had the possibility to
switch your KEYBOARD ON or OFF. With the programmable control panel the basic (test
subject) side of the unit is default OFF. It is possible to control the ergometer with the buttons
of the basic control panel instead of the programmable control panel. You can use this option
for service purposes or to program the display of the basic control panel. During the startup of
the ergometer you can press one of the buttons at the basic side to switch operation to this
basic control panel, you will then loose the control function of the programmable side. To go
back to the default control situation you have to restart the ergometer without pressing any
button.
The TEST FUNCTIONS are only available at the basic control panel. They are meant for
service personnel only. Contact your supplier in case service of the device is required.
