D Blood pressure option 928817, -818, 820
With option 928817, -818, 820 it is possible to perform stand alone or external controlled
blood pressure measurements. After installation the BP module is recognized automatically at
start up of the ergometer, indicated by the following screen for a few seconds:
D.1 Using the BP system
Caution
: Carefully read the instructions in Appendix D.2 Patient Hook-up before continuing.
Only well trained medical personnel, familiar with BP measurement, should operate the BP
system.
When you are in the MANUAL, TERMINAL or ANALOG mode you can go to the BP
measurement by pressing
( )
button. The following menu appears:
In the upper line of the display still your selected readout parameters appear. The buttons
below have the following functions:
▼ dis
: Toggle the display between your readout parameters and the pressure p [mm
Hg]. Pressure is indicated as lower case p and workload with upper case P.
▲
►
: The BP measurement starts:
With the same button the BP can be aborted at any time and the pressure will be released.
( ) MAN / TERM / ANA
: Return to the operation mode where you started from
(MANUAL, TERMINAL or ANALOG).
During the first BP measurement of the test subject the cuff inflates to 180 mm Hg. For each
subsequent BP measurement, the last measured SYSTOLIC value +50 mm Hg is used as a
maximum inflation limit. Be aware that in case of an error (D.3) the inflate limit can go up to
260 mmHg worst case. Above 300 mm Hg, or if a measurement lasts longer than 180
seconds, the hardware releases pressure immediately for safety reasons. Deflation is done 40
