the total protocol and define the recovery stage before you leave this menu otherwise the
changes will not be saved.
B.3.7.3 Protocol Run
The menu PROTOCOL RUN is used to select the desired protocol for the exercise test. Select
Protocol Run and three previously programmed protocols will appear on screen. To scroll
through the total list use the arrows, for instance:
If you want to select e.g. the protocol 10 w min, use the
▼
key until a space appears in front of
the name of the protocol (the selectable item is always on the 2
nd
line) and confirm with ok.
The following message will appear on screen:
This screen is used to check the selected protocol; in this case the name is 10w min: the first
step will start with 10 watt for 1 minute. Press the confirmation button to go on:
The ergometer is ready for use with the selected protocol. When the test subject exceeds the
30 rpm the protocol will run. You will see the following screen:
