Loepfe YARNMASTER ZENIT+ - Installation

3
First Startup Zenit
+
Variant 1
External power supply
24 V DC
Variant 3
External power supply
24 V DC
Variant 2
External power supply
90–264 V AC
Central unit (LZE-V)
Power
supply
unit
24 V DC
Spindle
adapter
(SA)
Loepfe 2-wire-bus (L2B)
Loepfe 2-wire-bus (L2B)
LAN connection (crossover cable)
Sensing head cable
Sensing head (TK)
1 Installation
Spindle
computer
or
All cable connections are pluggable.
Central unit
(LZE-V Faceless)
