Loewe Art - Function of the connections

Connect ID 40-55 - 39 -
Quick guide
english
Function of the connections
The following table shows the name, type and function of the ports.
Designation Type Function / Signal
Mains socket 220-240 V ~ 50 / 60 Hz Supply voltage
RJ12 Data I/O: serial interface
Mini AV
Video IN:
Audio IN:
withS-Video adaptor:
with VGA adaptor:
Y/C (S-VHS/Hi 8)
CVBS (VHS/8 mm)
PC/STB video signal
Component (YPbPr)
L/R
IEC socket 75 Ohm / 5 V / 80 mA:
Antenna (analogue) / Cable (analogue) /
DVB-T/T2 / DVB-C
F socket 75 Ohm / 13/18 V / 400 mA: ANT-SAT DVB-S/S2
Cinch (orange) SPDIF OUT: Digital audio output
HDMI4
HDMI type A (4x)
Digital Video/Audio IN
(HDMI1, HDMI2, HDMI3,
HDMI4):
Digital Audio OUT
(HDMI1 via HDMI ARC):
Digital video and audio
RJ-45 Ethernet / Fast Ethernet: Network interface
USB type A (3x) USB 2.0 (max. 500 mA): Multimedia files/software update
Mini AV
Video IN:
Audio IN:
with S-video adaptor: Y/C (S-VHS/Hi 8)
CVBS (VHS/8 mm)
RGB
L/R
Jack 3.5 mm Headphones 32–200 Ohm
CI Slot Common Interface: Slot for CA module

Connections rear side of the device
