Loewe Individual 55 Compose 3D - Page 28

- 28
english
 Set LNB frequencies.
You do not normally need to change the values.
OK Proceed.
(with Setting options for DVB-S reception (continued)
on page 31).
Setting options for the satellite system
(max. 4 satellites on DiSEqC multiswitch):
 Select and adapt settings for the DiSEqC multi-
switch.
The refresh rate determines how often a DiSEqC
command is output. A refresh is only necessary with
cascaded systems.
The control voltage controls the switching of the
polarisation level (horizontal/vertical) in non-DiSEqC
capable components (e.g. control of single LNBs via
DiSEqC multiswitch).
The 22kHz signal controls the switching between high
and low band in the Band setting. The Position setting
controls the selection of the satellites in non-DiSEqC
capable components.
The Toneburst controls the selection of the satellites in
non-DiSEqC but toneburst capable components with the
Position and Option settings.
OK Proceed
 Select Satellite 1 ... Satellite 4,
 select satellites from list,
OK Proceed.
 Select network.
If several networks are available over DVB-S, you
can decide which network you want to receive your
channels from.
OK Proceed.
Initial installation
Settings
DiSEqC
multiswitch
Repeat rate
Control
voltage
22kHz signal
Toneburst
Satellite
selection
Network
selection
OK
INITIAL INSTALLATION (DVB-S)
Repeat rate none 1 2
Control voltage 13/18V on
22kHz signal Band
Toneburst off
Proceed Back
OK
INITIAL INSTALLATION (DVB-S)
Satellite selection
Satellite 1 Astra1 19,2°E ...
Satellite 2 Hot Bird 13°E
Satellite 3 Eutelsat W2 16°E
Satellite 4 none
Proceed Back
OK
INITIAL INSTALLATION (DVB-S)
LNB frequencies
ASTRA1 19,2°E Low band 9750 MHz
ASTRA1 19,2°E High band 10600 MHz
Hot Bird 13°E Low band 9750 MHz
Hot Bird 13°E High band 10600 MHz
Eutelsat W2 16°E Low band 9750 MHz
Eutelsat W2 16°E High band 10600 MHz
Proceed Back
LNB
frequencies
OK
Proceed Back
INITIAL INSTALLATION
Network selection
other network
CanalDigitaal
OK
