CHASSIS REPLACEMENT PARTS LIST
Warning: Before servicing this chassis, read the “X-ray radiation precaution”, “Safety precaution” and “Product safety notice”
instructions on page 3 of this manual.
CAUTION: The international hazard symbols “ ” in the schematic diagram and the parts list designate components which have
special characteristics important for safety including X-Ray and should be replaced only with types identical to those in
the original circuit or specified in the parts list. The mounting position of replacements is to be identical with originals.
Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE. Do not degrade the safety of
the receiver through improper servicing.
CAL 2323 Art.-Nr. 59414.00
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N
°
. List Part N
°
. Var.
BAUGRUPPEN UNITS
830 LPL.Frequenzweiche kpl. ...................... Print Circuit Board ......................... 396-85729063
970 VGA EBS A2400 ................................... Scaffolding Access ........................ 291-87808002
980 Adapter A2400 kpl. ................................ Print Circuit Board ......................... 396-87957050
U2400 BAS-B. kpl. A2400 TU-USP99,US/33" .. Print Circuit Board ......................... 396-87715073
U2401 SIG-B. kpl. A2400 .................................. Print Circuit Board ......................... 396-87934050
U3371 Bildrohrpl./SVM kpl. A2400 4:3 .............. Print Circuit Board ......................... 396-87833053
U8211 LPL.Bedienung kpl. A2400 .................... Print Circuit Board ......................... 396-87506081
DRUCKSACHEN OPERATING INSTRUCTIONS
500 BAN für USA-Geräte -GB- ..................... Operating Instruction ..................... 233-27832002
570 Garantie u. Antwortkarte USA ............... Guaranty Card ............................... 224-28352
580 Bed.-Kurzanleitung USA ....................... Operating Instruction ..................... 233-28345002
GERÄTEBEIPACK SET SUPPLEMENT
A0640 Mikrozelle 1,5V Alkali-Mangan ............ Battery ........................................... 280-13411
N331 Adapter Mini-DIN/Chinch USA ............... Connecting Cable .......................... 169-88021001
N402 Subwoofer Adapter ................................ Socket ........................................... 323-86788
U0002 Adapter Antenne IEC-F männlich .......... Socket ........................................... 323-28138
U9111 IR-Fernbedienung Control USA arktis . Transmitter .................................... 263-87000063
VERPACKUNGSMATERIAL PACKING MATERIAL
102 Schutzstreifen (A) .................................. Protecktive Packing ....................... 253-20816
600 Verpackungskarton LO-Druck ............. Packing Case ................................ 245-86271702
610 Packschalen-Satz 33" ARC/CAL ........... Cushion-Set................................... 252-86273750
J0701 Schutzstreifen 350 x 190 mm (IR-G.) .. Protecktive Packing ....................... 253-84666004
VERBINDUNGSLEITUNG CONNECTING CABLES
N8102 Netzkabel USA m. Drossel 3200lg ........ Power Cord ................................... 170-87684002
KNÖPFE BUTTONS
303 Knopf II/Netzschalter USA/Tandberg ..... Button ............................................ 682-85749012
320 Knopf/Taster schwarz .......................... Button ............................................ 682-85081111
CAL 2323 Art.-Nr. 59414.00
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N
°
. List Part N
°
. Var.
GEHÄUSETEILE CABINET MOUNTING
111 Halter/RW.............................................. Holder ............................................ 602-85723101
112 Schraube M4,0x10-4.8 f.RW-Befest. ..... Screw ............................................ 435-24094
GEHÄUSETEILE CABINET MOUNTING
113 EJOT-PT-Schraube 4,0x14 KB40x14 . Screw ............................................ 440-27773
200 Distanzstück .......................................... Clutch Piece .................................. 503-24754
230 Halter/Entmag. ...................................... Holder ............................................ 602-84286101
301 Träger/Bed. Bedr. .................................. Supporter ...................................... 541-85747702
311 Magnet F.Gehäuse .............................. Magnet .......................................... 303-85893005
G100 33" Gehäuse graphit .............................. Cabinet .......................................... 750-86277705 L00
G100 33" Gehäuse brillantsilber CAL ............. Cabinet .......................................... 750-86277707 T00
G101 Zwischenstück natur ............................ Cover ............................................. 568-85727101 T00
G101 Zwischenstück schwarz ....................... Cover ............................................. 568-85727102 L00
G110 Rückwand graphit 33"........................ Backcover ..................................... 775-86278712 L00
G110 Rückwand brillantsilber 33"................ Backcover ..................................... 775-86278715 T00
G111 Zwischenstück natur ............................ Cover ............................................. 568-85727101 T00
G111 Zwischenstück schwarz ........................ Cover ............................................. 568-85727102 L00
G310 Klappe/Bed. brillantsilber vorm. USA ..... Cover Plate .................................... 706-85748081 T00
G310 Klappe/Bedien.vorm. graphit USA ......... Cover Plate .................................... 706-85748082 L00
G350 Ziergitter graphit .................................. Speaker Grille ................................ 708-86276005 L00
G350 Ziergitter brillantsilber .......................... Speaker Grille ................................ 708-86276007 T00
H0730 Chassishalter rechts ............................ Holder ............................................ 602-81482121
H0731 Chassishalter links ............................... Holder ............................................ 602-81481101
H0732 Gewindelasche M 4 F.RW-Befestigung Guide Strap ................................... 561-81547101
H1996 Abdeckung ............................................ Mask .............................................. 703-87883711
V0000 33Z „PH“A80-EFF002X43 ..................... Picture Tube .................................. 345-26133
SPULEN/LAUTSPRECHER COILS, SPEAKERS
800 Lautsprecher 4 Ohm 20W TT ............... Loudspeaker .................................. 272-87846
810 Lautsprecher 4 Ohm 20W HT ............... Loudspeaker .................................. 272-86411
L6001 Entmagn. Spule 32/33" A2400 .............. Coil ................................................ 297-88037001
